SKF 32216T78J2/QDBC110
Fiyatı: 9,257.62 ₺
Özellikler
| Marka | SKF |
| Ürün No | 32216T78J2/QDBC110 SKF |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 80 |
| Dış (D) MM | 140 |
| En (B) MM | 78 |
| İç (d) Inch | 3.1496 |
| Dış (D) Inch | 5.5118 |
| En (B) Inch | 3.0709 |
| Ağırlık | 4.45 kg |
| Tapered Roller Pair Internal Play | DB-standard Paired Metric O-ar |
| T78 | T, Followed By A Figure, Identifies The Total Width Of Bearing Pairs Arranged Back-To-Back Or In Tandem |
| J2 | Pressed Steel Window-Type Cage. A Figure Following The J Indicates A Different Cage Design |
| Q | Optimized Contact Geometry And Surface Finish |
| DB | Matched Bearings Pair Arranged Back-To-Back. A Figure Combination Immediately Following The DB Identifies The Design Of The Intermediate Rings |
| C110 | Axial Clearance in µm |
